Full automatic glazed tile roof tile making machine price

FOB Reference Price:Get Latest Price
$9,000.00 - $15,000.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Type:
Tile Forming Machine
Production Capacity:
3-4 m/min
Power(W):
5.5kw+5.5kw
Certification:
TUV / ISO / CE
Condition:
New
Place of Origin:
Hebei, China
Brand Name:
QJ
Model Number:
Customizable
Voltage:
380V 50HZ 3 Phase
Weight:
5500kg
Use:
Roof
Dimension(L*W*H):
6500*1700*1500mm
Tile Type:
Colored Steel
Suitable material:
PPGI/GI/PPGL/AL
Material Thickness:
0.2-1.0mm
Color:
blue or as the request
Roller station:
10-15
Roller material:
45# Forged Steel
Pressing type:
Hydraulic Guide Pillar Cutting
Cutting type:
Hydraulic Guide Pillar Cutting
Cutting blade material:
Cr12 Quenching
Under frame:
350 / 400 H-beam
Name:
Full automatic glazed tile roof tile making machine price
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
12 Months
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
Nude roll forming machine will be packed in 40 feet container with steel rope fixed.
Other small components will be packed with waterproof cloth and cardboard.
If the machine is too long, we will divide it into two parts and pack them in one package with welding.
Port
Tianjin Port
Lead Time :
Shipped in 30 days after payment

Full automatic glazed tile roof tile making machine price

roll forming machine 4.jpg
Product show

roll forming machine f22.jpg

Key Parameters





Glazed tile roll forming machine

key parameters

ModelYX 28-196-980YX 27-207-1035YX 24-183.3-1100
Sampleglazed tile 1.jpgglazed tile 2.jpgglazed tile 3.jpg
Roller stations151110
Suitable materialPPGI/GI/PPGL/ALPPGI/GI/PPGL/ALPPGI/GI/PPGL/AL
Main motor power5.5kw5.5kw5.5kw
Hydraulic station power5.5kw5.5kw5.5kw
Cutting typeHydraulic cutting with 2 guide pillars and 2 cylinders
Pressing typeHydraulic cutting with 4 guide pillars and 1 cylinder
Shaft typeSolid 70mm diameter, 45# steel and key-way processing
Roller processing

High grade 45# steel

with forging treatment, CNC lathed, polished and chrome plated

PLCDelta/Mitsubishi
HIM touch-screenDelta/Touch-win
Sidewall thickness16mm
Under frame400 H-beam400 H-beam350 H-beam
Chain size1 inch

Note:  Above is standard parameters.

           For latest information, please contact us to ask for.

Product Details

Customizable machine is available according to your specail requirements.

Please contact us to ask for specific profile drawing catalog.



>>Main features

# High precision and high efficiency
# Made of premium matarials
# Full-automatic PLC control system
# Customization is Acceptable

 >>Glazed tile roll forming machine equipment parts

Manual decoiler>>Feeding platform>>Cold rolling mills>>Computer control system

>>Hydraulic pressing device>>Hydraulic cutting device

>>Hydraulic system>>Counter>>Exit rack



roll forming machine.jpg

About Us
about us 1.jpg
about us 2.jpgAs a professional and leading supplier, we can design, manufacture, install various types of cold roll forming machinery, involving metal roof wall panel, glazed roof tile, C & Z steel purlin, floor decking, roof ridge cap, sandwich panel, roof truss, shutter panel, shutter slat, door frame, guardrail, and metal sheet uncoiler, bending, slitting, cutting, flattening, punching, crimping, etc.
Depending on reasonable design, precise machining and selected materials, both standard and customized machines are characterized by long life span, precise forming and easy operation. With our customers’ trust, our machines have been exported to America, Australia, Russia, India, Sri Lanka, Nigeria, Pakistan,Uzbekistan, Mozambique, Angola, Turkey, Brazil, etc. It is sure that all requirements can be satisfied for global different markets.about us 3.jpg
