CNC Double Layer Roof Sheeting Making Machine

  • >=1 Sets
    $24,000.00
Model Number:
1000-1035
Power(W):
5.5KW+5.5KW
Customization:
OEM (Min. Order: 1 Sets)
Samples:
$24,000.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Type:
Tile Forming Machine
Production Capacity:
15-20m/min
Certification:
CE/ISO9001/BV
Condition:
New
Place of Origin:
China
Brand Name:
QJ
Voltage:
380V 50Hz 3phases
Weight:
8500KG
Use:
Roof
Dimension(L*W*H):
9200*1500*1500
Tile Type:
Colored Glaze Steel
Applicable Industries:
Manufacturing Plant
Key Selling Points:
Easy to Operate
Machine Type:
Double Layer roofing roll forming machine
Roller Station:
16 steps(up) /18 steps(down)
Shaft Diameter:
70mm-0.03mm
Roller Material:
High grade 45# Steel,quenched,heat-treatment with hard chrome 0.05mm
Shaft Material:
High-grade 45# Steel,quenched
Control System:
Delta/Mitsubishi PLC
Cutting type:
Hydraulic Guide Pillar cutting
Length Tolerance:
10m+/-1mm
Pump Power:
5.5KW
Motor Brand:
Lichao,Shanghai
After-sales Service Provided:
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
Warranty:
18 months
Supply Ability
Supply Ability:
20 Set/Sets per Month steel roof tile machine
Packaging & Delivery
Packaging Details
1 Main forming machine and un-coiler is naked. 2 Tighten to container with steel wirerope and welded machine with container by angel iron. 3 PLC system and motor can be packed in waterproof plastic coverage if needed and necessary. Three sets of roll forming machine can be loaded in one 20-foot container
Port
Tianjin port
Video Description

-02_01

Product Description

1.High Precision And Speed

2.CE,ISO certification

3.Customization Accept

Suitable material

Color steel sheet , galvanized steel sheet,

Main motor power

5.5KW with Cycloidal reducer

Hydraulic station power

5.5KW

Hydraulic oil

40#

Thickness

0.3mm~0.8mm

Diameter

Φ70mm

Material expand width

1200mm-1250mm

Electric tension

380V 3phase 50HZ

Material of roller

High grade 45# forged steel

Rolling galvanization thickness

0.05mm

Processing speed

15-20m/min

Processing precision within

10m+/-1.00mm

Material of cutting blade

Cr12 quenched

Product Display

 .jpg

Company Information

Product Application

-01_05


Product Categories

Packaging & Shipping

2

1.We have professional technicians for loading

   Guaranteed the goods load into container without any damage.

2.Transportation : Machines need one 40 feet container to hold.

FAQ

Q1. What's your delivery time?
A1:Depending on the type of machine, duration of 1.25 days to 60 days from the date of order.

Q2. Do you have after-sales support?
A2:Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.


Q3. Do you sell only standard machines?
A3:No, most of our machines are built according to customers specifications,using top brand components.

Q4. What will you do if the machine is broken?
A4:Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts replace the broken parts freely,but you need pay the express cost yourself.If it is beyond the warranty period,we can negotiate to solve the problem,and we supply the technical support for the whole life of the equipment.


Q5. Can you be responsible for transport?
A5:Yes,please tell me the destination port or address.we have rich experience in transporting.



Q6. How to visit your company?
A6: 1) Fly to Beijing airport, By high speed train From Beijing Nan to Cangzhou Xi (1 hour).
      2) Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.
